    Arm Sealing Kit 31Y1-32450 31Y132450 For Hyundai R250LC-9 R260LC-9S Hydraulic Cylinder Seal Repair Kit

    Ask Lasest Price
    Brand Name : SUNCAR
    Model Number : 31Y1-32450 HYUNDAI R250LC-9, R250LC-9A, R260LC-9S, R260LC-9A, HX260L
    Price : Negotiation
    Payment Terms : Western Union, L/C, T/T, , D/A, D/P
    Supply Ability : 500 Piece per Week
    Delivery Time : 3-5 days after payment received(public holiday excluded)
    • Product Details
    • Company Profile

    Arm Sealing Kit 31Y1-32450 31Y132450 For Hyundai R250LC-9 R260LC-9S Hydraulic Cylinder Seal Repair Kit

    Arm Sealing Kit 31Y1-32450 31Y132450 For Hyundai R250LC-9 R260LC-9S Hydraulic Cylinder Seal Repair Kit


    Product NameArm Cylinder Seal Repair Kit
    Part Number31Y1-32450, 31Y132450
    Model

    9-SERIES CRAWLER EXCAVATOR R250LC-9, R250LC-9A, R260LC-9S, R260LC-9A;

    F-SERIES CRAWLER EXCAVATOR HX260L Hyundai

    MaterialPU, Rubber, PTFE, NBR, HNBR, ACM, VMQ
    Place of OriginChina(Mainland)
    Brand nameSUNCAR
    PackingPP bag inside, carton box outside
    Shipping ModeBy air, by sea, by express(FedEx, UPS, DHL, TNT, etc.)
    Payment TermsWestern Union, Paypal, T/T, Transfer
    CertifiC.A.TionISO9001
    WarrantyUnavailable
    CustomizedOEM & ODM are welcomed
    C.A.Tegory GroupHydraulic cylinder seal kit, excavator service kits
    ConditionNew, genuine new
    SampleAvailable
    Applicable Industries

    Building material shops, machinery repair shops, retail,

    construction work...

    FeatureHigh sealing performance/ wear resistance
    AppliC.A.TionArm

    Related Parts:

    Pos.Part NoQtyParts name
    *.31Q7-50130[1]ARM CYLINDER ASSY
    *-1.31Y1-32191[1]ARM CYL SUB ASSY
    131Y1-32200[1]TUBE ASSY
    231Y1-32260[1]ROD ASSY
    331Y1-32321[1]GLAND
    4S732-105040[1]BUSHING-DD2
    5Y191-112000[1]RING-SNAP
    K6.Y220-105013[1]SEAL-ROD
    K7.Y180-105120[1]RING-BACK UP
    K8.Y240-105012[1]RING-BUFFER
    K9.Y110-105011[1]WIPER-DUST
    10Y190-121000[1]RING-SNAP
    K11.S631-135004[1]O-RING
    K12.31YC-CP135[1]RING-BACK UP
    1331YC-28090[1]RING-CUSHION
    1431Y1-32360[1]PISTON
    K15.Y420-145000[1]SEAL-PISTON
    K16.Y310-145003[2]RING-WEAR
    K17.Y440-145102[2]RING-DUST
    K18.S632-080004[1]O-RING
    K19.S642-080003[2]RING-BACK UP
    2031YC-68090[1]NUT-LOCK
    21S114-100164[1]SCREW-SET
    K22.S632-145004[1]O-RING
    23S109-200904[12]BOLT-SOCKET
    2461Q6-97420[2]BUSHING-PIN
    K25.Y020-090100[4]SEAL-DUST,DLI,KPU
    2631YC-2A070[1]VALVE-CHECK
    2731YC-99071[1]SPRING-COIL
    K28.S631-014004[1]O-RING
    29P220-110103[1]PLUG-HEX
    3031Y1-32380[1]BAND ASSY-R
    30-1.31Y1-32390[1]BAND SUB ASSY
    30-2.31YC-31460[1]BAND
    30-3.S015-120452[2]BOLT-HEX
    30-4.S411-120002[2]WASHER-SPRING
    30-5.S070-053442[1]U-BOLT
    30-6.S205-101002[2]NUT-HEX
    30-7.S411-100002[2]WASHER-SPRING
    3131Y1-32400[1]BAND ASSY-B
    31-1.31Y1-32410[1]BAND SUB ASSY
    31-2.31Y1-32420[1]BAND SUB ASSY
    31-3.S015-120452[2]BOLT-HEX
    31-4.S411-120002[2]WASHER-SPRING
    31-5.S070-053442[1]U-BOLT
    31-6.S205-101002[2]NUT-HEX
    31-7.S411-100002[2]WASHER-SPRING
    3231Y1-32430[1]PIPE ASSY-R
    K33.Y171-024004[1]O-RING
    34S107-120554[4]BOLT-SOCKET
    K.31Y1-32450[1]SEAL KIT

    Order Process:

    1. Getting your inquiry (Including: machine model, part name, order quantity, data of items, delivery term)

    2. Quoting our competitive price for you

    3. Place an order after approving the quotation or products

    4. We will send Proforma Invoice or sales confirmation

    5. You prepay by T/T or L/C or Western Union through bank

    6. We will starting to produce after we get your kind payment

    7. Packing

    8. Shipping the goods to your(our)forwarder

    9. Sending all doc for your custom clearance

    10. Time to reorder
